Bryant EVOLUTION 180B - DIMENSIONS - 187 BNA 2-5 TON (ENGLISH)

8
DIMENSIONS -- 187BNA 2--5 TON (ENGLISH)
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
- 26" X 26"
24,36 31 1/2" X 31 1/2" 48,60 35" X 35"
UNIT SERIES
ELECTRICAL
CHARACTERISTICS
ABCDEFGKLMNP
OPERATING
WEIGHT (lbs)
SHIPPING
WEIGHT (lbs)
SHIPPING
DIMENSIONS (L x W x H)
187B024 A X O O O 31 3/16" 38 15/16" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 14 1/4" 17 1/4" 19 1/2" 222 261 32 15/16" X 35 1/2" X 46 1/8" 187B036 A X O 0 0 31 3/16" 38 15/16" 3 7/8" 7/8" 6 9/16" 24 11/16" 9 1/8" 2 15/16" 5/8" 14 1/4" 17 1/4" 19 1/2" 224 263 32 15/16" X 35 1/2" X 46 1/8" 187B048 A X O 0 0 35" 40 1/4" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 18" 17 1/2" 20" 324 381 36 1/8" X 39 1/4" X 46 1/8" 187B060 A X O 0 0 35" 47 1/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17 7/8" 18 5/8" 21" 334 391 36 1/8" X 39 1/4" X 50 13/16"
X = YES O=NO
A
B
C
31/2"
17/8"
P
E
F
N
G
M
L
3"
5/16"
K
SQ.
FIELD CONTROL
SUPPLY CONN.
7/8" HOLE
FIELD POWER SUPPLY
CONN. 7/8" HOLE
WITH 1 1/8" KNOCKOUT
3/8"
LIQUID LINE CONN.
VAPOR LINE CONN.
D
AIR DISCHARGE
3/8" TIEDOWN HOLE
(2) PLACES
AIR IN
AIR IN
AIR IN
AIR IN
AIR DISCHARGE
187B / 180B
