559K*05 ELECTRIC HEAT DATA — WITH NON-FUSED DISCONNECT
559K
UNIT
SIZE
NOM.
V-Ph-Hz
IFM
TYPE
ELECTRIC HEATER
PART NUMBER
NOM
(kW)
APPLICATION
(kW)
APPLICATION
OUTPUT
(MBH)
SINGLE POINT OR JUNCTION PART NUMBER
CRSINGLEXXXA00
NO C.O. OR UNPOWERED
C.O.
w/PWRD C.O.
NO P.E.
w/P.E.
(pwrd fr/unit)
NO P.E
w/P.E.
(pwrd fr/unit)
*05
208/230-1-60
STD
CRHEATER323A00 4.4 3.3/4.0 11.3/13.8 037 037 — —
CRHEATER325A00 8.7 6.5/8.0 22.3/27.3 037 037 — —
CRHEATER327A00 13.0 9.8/11.9 33.3/40.7 040 040 — —
CRHEATER329A00 17.4 13.1/16.0 44.6/54.5 040 040 — —
CRHEATER330A00 19.2 14.4/17.6 49.2/60.2 040 040 — —
CRHEATER331A00 21.0 15.8/19.3 53.8/65.8 040 040 — —
MED
CRHEATER323A00 4.4 3.3/4.0 11.3/13.8 037 037 — —
CRHEATER325A00 8.7 6.5/8.0 22.3/27.3 037 037 — —
CRHEATER327A00 13.0 9.8/11.9 33.3/40.7 040 040 — —
CRHEATER329A00 17.4 13.1/16.0 44.6/54.5 040 040 — —
CRHEATER330A00 19.2 14.4/17.6 49.2/60.2 040 040 — —
CRHEATER331A00 21.0 15.8/19.3 53.8/65.8 040 040 — —
HIGH
CRHEATER323A00 4.4 3.3/4.0 11.3/13.8 037 037 — —
CRHEATER325A00 8.7 6.5/8.0 22.3/27.3 037 037 — —
CRHEATER327A00 13.0 9.8/11.9 33.3/40.7 040 040 — —
CRHEATER329A00 17.4 13.1/16.0 44.6/54.5 040 040 — —
CRHEATER330A00 19.2 14.4/17.6 49.2/60.2 040 040 — —
CRHEATER331A00 21.0 15.8/19.3 53.8/65.8 040 040 — —
208/230-3-60
STD
CRHEATER323A00 4.4 3.3/4.0 11.3/13.8 037 037 037 037
CRHEATER324A00 6.5 4.9/6.0 16.7/20.4 037 037 037 037
CRHEATER325A00 8.7 6.5/8.0 22.3/27.3 037 037 037 037
CRHEATER328A00 16.0 12.0/14.7 41.0/50.1 037 037 038 038
CRHEATER330A00 19.2 14.4/17.6 49.2/60.2 038 038 038 038
CRHEATER331A00 21.0 15.8/19.3 53.8/65.8 038 038 038 038
MED
CRHEATER323A00 4.4 3.3/4.0 11.3/13.8 037 037 037 037
CRHEATER324A00 6.5 4.9/6.0 16.7/20.4 037 037 037 037
CRHEATER325A00 8.7 6.5/8.0 22.3/27.3 037 037 037 037
CRHEATER328A00 16.0 12.0/14.7 41.0/50.1 037 037 038 038
CRHEATER330A00 19.2 14.4/17.6 49.2/60.2 038 038 038 038
CRHEATER331A00 21.0 15.8/19.3 53.8/65.8 038 038 038 038
HIGH
CRHEATER323A00 4.4 3.3/4.0 11.3/13.8 037 037 037 037
CRHEATER324A00 6.5 4.9/6.0 16.7/20.4 037 037 037 037
CRHEATER325A00 8.7 6.5/8.0 22.3/27.3 037 037 037 037
CRHEATER328A00 16.0 12.0/14.7 41.0/50.1 037 037 038 038
CRHEATER330A00 19.2 14.4/17.6 49.2/60.2 038 038 038 038
CRHEATER331A00 21.0 15.8/19.3 53.8/65.8 038 038 038 038
460-3-60
STD
CRHEATER333A00 6.0 5.5 18.8 — — — —
CRHEATER335A00 11.5 10.6 36.0 — — — —
CRHEATER336A00 14.0 12.9 43.9 — — — —
CRHEATER337A00 21.5 19.7 67.4 037 037 037 037
MED
CRHEATER333A00 6.0 5.5 18.8 — — — —
CRHEATER335A00 11.5 10.6 36.0 — — — —
CRHEATER336A00 14.0 12.9 43.9 — — — —
CRHEATER337A00 21.5 19.7 67.4 037 037 037 037
HIGH
CRHEATER333A00 6.0 5.5 18.8 — — — —
CRHEATER335A00 11.5 10.6 36.0 — — — —
CRHEATER336A00 14.0 12.9 43.9 — — — —
CRHEATER337A00 21.5 19.7 67.4 037 037 037 037
575-3-60
STD
CRHEATER339A00 10.0 9.2 31.3 — — — —
CRHEATER340A00 15.0 13.8 47.0 — — — —
MED
CRHEATER339A00 10.0 9.2 31.3 — — — —
CRHEATER340A00 15.0 13.8 47.0 — — — —
HIGH
CRHEATER339A00 10.0 9.2 31.3 — — — —
CRHEATER340A00 15.0 13.8 47.0 — — — —
