96
Legend and Notes
Applicable for Electrical Data Tables on pages 97 to 117
LEGEND
NOTES:
1. In compliance with NEC requirements for multi-motor and combi-
nation load equipment (refer to NEC Articles 430 and 440), the
overcurrent protective device for the unit shall be fuse or HACR
breaker. Canadian units may be fuse or circuit breaker.
2. For 208/230 v units, where one value is show it is the same for
either 208 or 230 volts.
3. Unbalanced 3-Phase Supply Voltage
Never operate a motor where a phase imbalance in supply voltage
is greater than 2%. Use the following formula to determine the per-
centage of voltage imbalance.
Example: Supply voltage is 230-3-60
Determine maximum deviation from average voltage.
(AB) 227-224 = 3 v
(BC) 231-227 = 4 v
(AC) 227-226 = 1 v
Maximum deviation is 4 v.
Determine percent of voltage imbalance.
This amount of phase imbalance is satisfactory as it is below the
maximum allowable 2%.
BRKR — Circuit Breaker
C . O . — Convenience Outlet
FLA — Full Load Amps
IFM — Indoor Fan Motor
LRA — Locked Rotor Amps
MCA — Minimum Circuit Amps
OFM — Outdoor (Condenser) Fan Motor
P.E. — Power Exhaust
PWRD C.O. — Powered Convenience Outlet
RLA — Rated Load Amps
UNPWR C.O.— Unpowered Convenience Outlet
% Voltage
Imbalance
= 100 x
max voltage deviation from average voltage
average voltage
AB = 224 v
BC = 231 v
AC = 226 v
Average Voltage =
(224 + 231 + 226)
=
681
= 227
3 3
% Voltage Imbalance = 100x
4
= 1.78%
227
IMPORTANT: If the supply voltage phase imbalance is more than
2%, contact your local electric utility company immediately.
Electrical data
