—14—
* Tested combination.
EER
— Energy Efficiency Ratio
SEER
— Seasonal Energy Efficiency Ratio
NOTES:
1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for
other combinations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Application of capillary tube coils is not recommended.
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOT. CAP. BTUH
SEER EERHigh Low High Low
060-A, B
CK5A/CK5BA060 1750 1050 58,000 29,400 14.5 10.4
CK5A/CK5BT060 1750 1050 58,000 29,400 14.5 10.4
CK5A/CK5BX060 1750 1050 59,000 29,600 15 10.5
CK5PA060 1750 1050 58,000 29,400 14.5 10.4
CK5PT060 1750 1050 58,000 29,400 14.5 10.4
CK5PX060 1750 1050 59,000 29,600 15 10.5
COILS + 315(A,J)066155 VARIABLE SPEED FURNACE
CC5A/CD5AA060 1750 1050 58,000 29,200 14.5 10.4
CC5A/CD5AW060 1750 1050 58,000 29,200 14.5 10.45
CE3AA060 1750 1050 58,500 29,200 14.5 10.5
CK3BA060 1750 1050 58,000 29,400 14.5 10.45
CK5A/CK5BA060 1750 1050 58,000 29,400 14.5 10.45
CK5A/CK5BT060 1750 1050 58,000 29,400 14.5 10.45
CK5A/CK5BX060 1750 1050 59,500 29,600 15 10.6
CK5PA060 1750 1050 58,000 29,400 14.5 10.45
CK5PT060 1750 1050 58,000 29,400 14.5 10.45
CK5PX060 1750 1050 59,500 29,600 15 10.6
COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
CC5A/CD5AA060 1838 1138 56,500 28,800 14.2 9.85
CC5A/CD5AW060 1838 1138 58,000 29,400 14.5 10.2
CE3AA060 1838 1138 58,500 29,600 15 10.45
CK3BA060 1838 1138 57,500 29,600 14.5 10.1
CK5A/CK5BA060 1838 1138 57,500 29,600 14.5 10.1
CK5A/CK5BT060 1838 1138 57,500 29,600 14.5 10.1
CK5A/CK5BX060 1838 1138 59,000 29,800 15 10.5
CK5PA060 1838 1138 57,500 29,600 14.5 10.1
CK5PT060 1838 1138 57,500 29,600 14.5 10.1
CK5PX060 1838 1138 59,000 29,800 15 10.5
COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA060 1838 1138 58,000 29,400 14.4 9.9
CC5A/CD5AW060 1838 1138 58,000 29,400 14.5 10.05
CE3AA060 1838 1138 58,500 29,600 14.5 10.05
CK3BA060 1838 1138 57,500 29,400 14.5 9.95
CK5A/CK5BA060 1838 1138 57,500 29,600 14.5 10
CK5A/CK5BT060 1838 1138 57,500 29,600 14.5 10
CK5A/CK5BX060 1838 1138 59,000 29,800 15 10.35
CK5PA060 1838 1138 57,500 29,600 14.5 10
CK5PT060 1838 1138 57,500 29,600 14.5 10
CK5PX060 1838 1138 59,000 29,800 15 10.35
COILS + 355MAV060080 VARIABLE SPEED FURNACE
CC5A/CD5AA060 2000 1200 57,500 29,800 13.5 9.15
CC5A/CD5AW060 2000 1200 59,500 30,000 14 9.4
CE3AA060 2000 1200 59,500 30,000 14 9.4
CK3BA060 2000 1200 58,000 30,000 13.5 9.25
CK5A/CK5BA060 2000 1200 58,000 30,000 13.5 9.25
CK5A/CK5BT060 2000 1200 58,000 30,000 13.5 9.25
CK5A/CK5BX060 2000 1200 59,500 30,000 14 9.45
CK5PA060 2000 1200 58,000 30,000 13.5 9.25
CK5PT060 2000 1200 58,000 30,000 13.5 9.25
CK5PX060 2000 1200 59,500 30,000 14 9.45
COILS + 355MAV060100 VARIABLE SPEED FURNACE
CC5A/CD5AA060 2000 1200 56,500 29,000 14 9.55
CC5A/CD5AW060 2000 1200 58,000 29,400 14 9.5
CE3AA060 2000 1200 58,500 29,800 14 9.55
CK3BA060 2000 1200 57,500 29,600 14 9.4
CK5A/CK5BA060 2000 1200 57,500 29,600 14 9.4
CK5A/CK5BT060 2000 1200 57,500 29,600 14 9.4
CK5A/CK5BX060 2000 1200 59,000 30,000 14.25 9.6
CK5PA060 2000 1200 57,500 29,600 14 9.4
CK5PT060 2000 1200 57,500 29,600 14 9.4
CK5PX060 2000 1200 59,000 30,000 14.25 9.6
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA060 2000 1200 58,500 29,400 14 9.7
CC5A/CD5AW060 2000 1200 58,500 29,400 14 9.75
CE3AA060 2000 1200 59,000 29,800 14.25 9.8
CK3BA060 2000 1200 57,500 29,600 14 9.65
CK5A/CK5BA060 2000 1200 58,000 29,600 14 9.65
CK5A/CK5BT060 2000 1200 58,000 29,600 14 9.65
CK5A/CK5BX060 2000 1200 59,000 30,000 14.35 9.85
CK5PA060 2000 1200 58,000 29,600 14 9.65
CK5PT060 2000 1200 58,000 29,600 14 9.65
CK5PX060 2000 1200 59,000 30,000 14.35 9.85
COMBINATION RATINGS Continued
