—38—
DETAILED COOLING CAPACITIES* continued
* Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240-94. If additional tubing length and/or
indoor unit is located above outdoor unit, a slight variation in capacity may occur.
† Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
‡ Sensible capacities shown are based on 80°F (27°C) entering air at the indoor coil. For sensible capacities at other than 80°F (27°C), deduct 835 Btuh (245
kw) per 1,000 CFM (480 L/S) of indoor coil air for each degree below 80°F (27°C), or add 835 Btuh (245°kw) per 1,000 CFM (480 L/S) of indoor coil air per
degree above 80°F (27°C). When the required data falls between the published data, interpolation may be performed.
** Unit kw is total of indoor and outdoor unit kilowatts.
†† At TVA conditions (75edb-63ewb). All other indoor air temperatures are at 80 edb.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
KW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
598B060-A, B Outdoor Section With FV4ANB006 Indoor Section - Low Speed Continued
1050
72 39.76 21.24 1.94 36.67 20.07 2.10 33.65 18.94 2.25 30.65 17.85 2.39 27.67 16.78 2.54 24.69 15.73 2.67
67 35.45 25.93 1.92 32.63 24.76 2.07 29.85 23.64 2.21 27.10 22.54 2.35 24.38 21.45 2.48 21.68 20.35 2.61
63†† 32.40 24.81 1.91 29.77 23.65 2.05 27.16 22.51 2.18 24.60 21.41 2.31 22.09 20.32 2.43 19.61 19.16 2.55
62 31.56 30.45 1.91 29.05 29.05 2.04 27.06 27.06 2.18 25.10 25.10 2.32 23.15 23.15 2.46 21.12 21.12 2.59
57 30.98 30.98 1.90 29.02 29.02 2.04 27.07 27.07 2.18 25.11 25.11 2.32 23.15 23.15 2.46 21.12 21.12 2.59
1350
72 41.34 23.37 2.04 38.00 22.15 2.21 34.69 20.96 2.36 31.46 19.81 2.51 28.27 18.69 2.65 25.12 17.61 2.79
67 36.86 29.31 2.03 33.78 28.08 2.18 30.73 26.86 2.33 27.79 25.63 2.46 24.94 24.33 2.60 22.40 22.40 2.73
63†† 33.67 27.97 2.02 30.76 26.72 2.16 27.94 25.47 2.30 25.23 24.21 2.42 22.66 22.66 2.56 20.48 20.48 2.69
62 33.52 33.52 2.02 31.28 31.28 2.17 29.08 29.08 2.31 26.87 26.87 2.45 24.66 24.66 2.59 22.41 22.41 2.73
57 33.53 33.53 2.02 31.29 31.29 2.17 29.09 29.09 2.31 26.88 26.88 2.45 24.66 24.66 2.59 22.41 22.41 2.74
1650
72 42.29 25.25 2.15 38.72 23.97 2.31 35.25 22.74 2.47 31.87 21.55 2.62 28.54 20.40 2.77 25.27 19.28 2.90
67 37.66 32.34 2.14 34.38 30.98 2.29 31.22 29.58 2.44 28.19 28.19 2.57 25.69 25.69 2.72 23.23 23.23 2.86
63†† 34.36 30.74 2.12 31.32 29.34 2.27 28.41 27.85 2.41 25.82 25.82 2.54 23.50 23.50 2.68 21.16 21.16 2.81
62 35.35 35.35 2.13 32.94 32.94 2.28 30.50 30.50 2.43 28.09 28.09 2.57 25.70 25.70 2.72 23.23 23.23 2.86
57 35.36 35.36 2.13 32.95 32.95 2.28 30.51 30.51 2.43 28.10 28.10 2.57 25.70 25.70 2.72 23.24 23.24 2.86
1950
72 42.84 26.94 2.25 39.14 25.63 2.42 35.54 24.36 2.58 32.05 23.15 2.73 28.63 21.98 2.87 25.24 20.80 3.01
67 38.12 34.99 2.24 34.77 33.42 2.40 31.61 31.61 2.55 28.99 28.99 2.69 26.40 26.40 2.84 23.80 23.80 2.98
63†† 34.80 33.11 2.23 31.66 31.65 2.38 29.03 29.03 2.52 26.55 26.55 2.66 24.09 24.09 2.80 21.61 21.61 2.94
62 36.78 36.78 2.24 34.15 34.15 2.39 31.56 31.56 2.55 29.00 29.00 2.69 26.41 26.41 2.84 23.81 23.81 2.98
57 36.79 36.79 2.24 34.16 34.16 2.39 31.57 31.57 2.55 29.01 29.01 2.69 26.42 26.42 2.84 23.81 23.81 2.98
2250
72 43.19 28.56 2.35 39.39 27.23 2.52 35.69 25.94 2.68 32.11 24.70 2.83 28.60 23.49 2.98 25.12 22.18 3.12
67 38.48 37.30 2.34 35.16 35.16 2.50 32.40 32.40 2.66 29.66 29.66 2.81 26.94 26.94 2.96 24.21 24.21 3.10
63†† 35.14 35.14 2.33 32.36 32.36 2.49 29.70 29.70 2.63 27.10 27.10 2.77 24.52 24.52 2.92 21.88 21.88 3.05
62 37.91 37.91 2.34 35.14 35.14 2.50 32.41 32.41 2.66 29.68 29.68 2.81 26.96 26.96 2.96 24.22 24.22 3.10
57 37.93 37.93 2.34 35.15 35.15 2.50 32.43 32.43 2.66 29.68 29.68 2.81 26.96 26.96 2.96 24.23 24.23 3.10
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
CK5A/CK5BA 060 1.00 1.08 CK5PA 060 0.99 1.04
CK5A/CK5BT 060 1.00 1.08 CK5PT 060 0.99 1.04
CK5A/CK5BX 060 1.00 1.08 CK5PX 060 1.00 1.04
CK5PA 060 1.00 1.08
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CK5PT 060 1.00 1.08 CC5A/CD5AA 060 0.98 1.04
CK5PX 060 1.00 1.08 CC5A/CD5AW 060 0.98 1.04
COILS + 355MAV060100 VARIABLE SPEED FURNACE CE3AA 060 0.99 1.04
CC5A/CD5AA 060 0.97 1.05 CK3BA 060 0.99 1.04
CC5A/CD5AW 060 0.98 1.03 CK5A/CK5BA 060 0.99 1.04
CE3AA 060 0.99 1.04 CK5A/CK5BT 060 0.99 1.04
CK3BA 060 0.99 1.04 CK5A/CK5BX 060 1.00 1.04
CK5A/CK5BA 060 0.99 1.04 CK5PA 060 0.99 1.04
CK5A/CK5BT 060 0.99 1.04 CK5PT 060 0.99 1.04
CK5A/CK5BX 060 1.00 1.04 CK5PX 060 1.00 1.04
