Loading
Grasping
the Control
Arm
(1)
at the rear, raise
it to
its
uppermost
position
and
swing counterclock-
wiseuntilitispositionedovertheTone
Arm
(3).
Place
upto a maximum
of six records,
which
must be
of
the
same speedand havethe
sametype
of
groove
(Standard
or
LongPlaying),
onthe
Spindle
(52).
The
first record
to be
played
must
be located carefully
on the ledge
of
thespindleandheld in
position
until
the remaining
re-
cords are loaded
on
the
Spindle,
then the Control Arm
shouldbe
returnedto
its
center operating
position
and
gently
lowered on to the record
stack.
Staiting
Makesure
that
the Tone Arm
CIip
(34)
has been
released. Move
the Starting
Lever Knob
(134)
fully
counterclockwise to the
"REJ"
position
and
hold until
theturntable(38)
starts to revolve.
Then, release
the
Starting
Lever
Knob.
Rejecting
To
rejecta record
at any time
when the changer
is in operation, turn the
Starting Lever Knob
counter-
clockwise to
"REJ"
position
and release.'
Stopping
The
record changer
may
be
stopped
at any time
bymovingthe
Starting Lever
Knob
to
the
"OFF"
posi-
tion. If
the
record
changer
is
stopped
during
the
"change
cycle", it must
be
allowed
to complete
that
cycle
(by
manual rotation
of the
turntable,
if
necessary)
before attempting
to lift the Control
Arm
and remove
the
records.
OPERATI
NG
INSTRUCTIONS
CHANGE
CYCLE
Un
loading
Raisethe
Control
Arm
to
its uppermost position
and
swing counterclockwise
until
it is
positioned
over
the Tone
Arm.
Using
both
hands,
grasp
the
edge
of
the bottom
record
and
gently
lift
the record
stack
straight up
and
off the
Spindle
(52).
After
unloading
a
stackof45
RPM
records
with
large
center
hole,
make
sure that
the
45
RPM
Spindle
(132)
is
properly
seated
before
playing
additional
45
RPM
records.
Manual
Operation
Raisethe
Control
Arm
to its
uppermost
position
and
swing counterclockwise
until
it is
positioned
over
the tone
arm. Place
the record
on
the
Turntable
and
return the
Control Arm
to its
operating
position.
Set
the
Speed
Selector
Knob
(6b)
to
provide
the
operating
speed for the
record
to
be
played
and
set the
proper
stylus inoperatingpositiononthe
Tone
Arm.
To
start,
movethe
Starting Lever
Knob
to
the
"MAN/ON"
posi-
tion
and
place
the
stylus
in
position
on the
record.
The
record
will
nowplay
and
when
completed,
the Tone
arm
will return
to the
Tone
Arm
Rest
(3b)
and
the
changer
willswitch
off in
the
normal manner
provided
that
the
recordbeingplayedhas
fast-finishing grooves,
If
not,
after
the
record
has
completed
playing,
the Tone
Arm
must
be
manually
returned
to
the Tone
Arm
Rest
and
theStarting
Lever
Knob
moved
to the
"OFF"
position.
Note:
Records
that
do not have
starting
or
fast-finish_
ing
grooves
must
be
played
manually.
General
lnformation
?he
change
cycle
is initiated
by
sliding the
Off-
Man-On-Rej control to the
'Rej"
position,
then re-
leasing.
Atthestartof
the change
cycle,
the
tone arm
islifted
from
the
tone arm
rest
and
a record
drops to
the turntable.
The
size
of the record
determines
whether
the
tone
arm
will set
down in
the ?-,
10-,
or
12-inch
position.
The
tone
arm
is moved
toward
the
spindleand
the
needle
is then
lowered
into
the
lead-in
groove
of the
record.
When
the
needle reaches
the
end
of the music
grooves
and enters
the
fast finishing groove
at the end
,of
the
record,
the
tone
arm
movement
toward
the
spindle
accelerates
rapidly
to
actuate
the
velocity
trip
mechanism.
The
tone
arm is
lifted
and returned
to a
positionoverthetone
arm
rest,
and
the bottom
record
on the
spindle
drops into
playing
position
on
the turn-
table. Thetonearmreturns
to
a
Fosition
over the re-
cordand
the
needle is
lowered
into
the
lead-in
groove
of
the record.
Thepreviously
described
actiontakes place
each
time
the end
of a record
is
reached
until
the
last
te-
cordhasplayed.
At
this
time,
the
velocity
trip
mech-
anisminitiates
another
change
cycle
and the
tone
arm
is
returned
to the tone
arm
rest.
A
moment
later,
automatic
shutoff
occurs.
NOTE: Thefollowingis
a complete
description
of
the
functions
thatthe
various parts
perform
dur-
ingachangecycle.
Observe
the
change
cycle
operation
while slowly
rotating
the
turntable
by hand.
The
following
description
can
then
be readily
lollowed
and the
function
of each
part
more
easily
understood.
