BTECH BT33 - Installation Instructions; Single threaded insert; Dual threaded insert

6
1
INSTALLATION INSTRUCTIONS
A/B/C
A/B/C
4
REAR OF
SPEAKER
6
5
Choose one of the four fixing methods shown that suits your speaker
fixings.
Attach part 4 to the speaker using screws A, B, C or D, or for
keyhole fixings use screw A and part E.
i. Single threaded insert.
ii. Dual threaded insert.
THIS MOUNT MUST BE DISASSEMBLED PRIOR TO INSTALLATION
