Bticino 344082 - Device Configuration; Handset Numbering; Entrance Panel Association; Key Operating Modes

2
BT00641-a
344082
-EN
TECHNICAL SHEETS
N - handset number
Assigns to each handset an identication number within the system. The handsets
must be congured in progressive order. Handsets with parallel connection (max 3 are
allowed inside apartments without item 346850) must be congured using the same
N congurator.
P - entrance panel association
The P congurator identies the associated EP, or the rst entrance panel on which the
audio is activated when the (
) key is pressed, as well as which door lock is activated
when the key
is pressed while the handset is idle.
M - Operating mode of the keys
In addition to the door lock opening key
and the staircase light key ( ), the
handset also has 4 programmable keys ( - - - ).
These keys may be associated to dierent operating modes (e.g. activation of external
actuators, intercom, activation of additional EPs, etc., based on the type of congurator
connected to M).
The handset oers the possibility to select among 16 types of bells with pre-programmed
ringtones, which can be associated to the following type of calls:
- Calls from the entrance panel (congured with S=0 - S=4)
- Calls from the entrance panel (congured with S=0 - S=5)
- Intercom call
- Floor call
(See the bell programming table in the following pages)
Conguration
Congurator in P key ( ) function
0-9 Entrance panel audio activation
(congured with P=0-9)
Congurator in P key
function
0-9 Opening of the EP door lock
(congured with P=0-9)
