Bticino K4027C User Manual

2
• Caratteristiche tecniche
• Technical features
• Caractéristiques techniques
• Technische Daten
• Características técnicas
• Technische eigenschappen
• Características técnicas
• Технические характеристики

• Smontaggio
• Disassembling
• Démontage
• Demontage
• Desmontaje
• Demontage
• Desmontagem
• Демонтаж


1
3
4
2
Il fabbricante, BTicino S.p.A., dichiara che il tipo di apparecchiatura radio Comando tapparella connesso art. K4027C è conforme alla direttiva 2014/53/UE.
Il testo completo della dichiarazione di conformità UE è disponibile al seguente indirizzo Internet: www.bticino.it/red
Hereby, BTicino S.p.A., declares that the radio equipment type Connected rolling shutter switch item K4027C is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: www.bticino.it/red
RAEE/WEEE: bticino.com/disposal
45+
+ 45 °C
+ 5 °C
5+
1 x 1,5 mm
2
1 x 1.5 mm
2
1 x 1,5 мм
2
21,51
100 – 240 Vac ; 50/60 Hz – 100 – 240 В ; 50/60 Гц
240-1106050
Carichi Motore tapparelle
240 VAC max. 1 x 500 VA
100 VAC max. 1 x 270 VA
Tecnologia Radio (Maglie di rete senza fili)
Livello di potenza <100mW
Frequenza di banda da 2,4 a 2,4835 GHz
Loads Motor for shutters
240 VAC max. 1 x 500 VA
100 VAC max. 1 x 270 VA
Technology Radio (Wireless meshed network)
Power level <100mW
Band frequency from 2,4 to 2,4835 GHz
Charges Moteur pour volets roulants
240 VAC max. 1 x 500 VA
100 VAC max. 1 x 270 VA
Technologie Radio (Réseau maillé sans fil)
Niveau de puissance <100mW
Fréquence de bande de 2,4 à 2,4835 GHz
Stromlasten Rollladenmotor
240 VAC max. 1 x 500 VA
100 VAC max. 1 x 270 VA
Technologie Radio (Maschen eines drahtlosen Netzes)
Leistungsniveau <100mW
Bandfrequenz von 2,4 bis 2,4835 GHz
Cargas Motor para persianas
240 VAC max. 1 x 500 VA
100 VAC max. 1 x 270 VA
Tecnología Radio (Mallas de red sin hilos)
Nivel de potencia <100mW
Frecuencia de banda de 2,4 a 2,4835 GHz
45+
+ 45 °C
+ 5 °C
5+
1 x 1,5 mm
2
1 x 1.5 mm
2
1 x 1,5 мм
2
21,51
100 – 240 Vac ; 50/60 Hz – 100 – 240 В ; 50/60 Гц
240-1006050
Ladingen Motor rolluiken
240 VAC max. 1 x 500 VA
100 VAC max. 1 x 270 VA
Technologie Radio (draadloos netwerkschakels)
Vermogensniveau <100mW
Frequentieband 2,4 t/m 2,4835 GHz
Cargas Motor para persianas
240 VAC máx. 1 x 500 VA
100 VAC máx. 1 x 270 VA
Tecnologia Rádio (links de rede sem fio)
Nível de potência <100mW
Frequência de banda de 2,4 a 2,4835 GHz
Нагрузка Двигатель жалюзи
240 В Пер.т макс. 1 x 500 ВА
100 В Пер.т макс. 1 x 270 ВА
Технология Радио (Ячейки беспроводной сети)
Уровень мощности <100мВт
Полоса пропускания от 2,4 до 2,4835 ГГц




1 240
1 100
 
100 
2,48352,4 
