Buderus 21 - Thermostatic Sensor Head; Temperature Control

14
|
Panel Radiator
Applications Manual
Panel Radiator Applications Manual | 03.2019
Technical specifi cations are subject to change without prior notice
Panel Radiator
2 / "- 2 / "
from nished
wall to center
of tapings
2" 1³/16"
Bracket
Supply
Return
Bracket
Minimum of
4"
2½"
1
/ "- 1 / "
1 2
TOP VIEW
Finished wall
Stud
5½"
Minimum of
4"
Fig. 8 Model 21 Panel Radiator Rough in Dimensions in inches
for wall mounting
Panel Radiator
3 / "- 3 / "
from
finished wall
to center of
tapings
Bracket
Supply
Return
Bracket
4"
Minimum of
4"
1 2
TOP VIEW
1 / "- 1 / "
Finished wall
Stud
2" 1³/16"
5½"
Minimum of
4"
Fig. 9 Model 22 Panel Radiator Rough in Dimensions in inches
for wall mounting
