h. Take hold of the wheeled board and turn the protruding lips between
the clamps and the axle. When rotating the wheeled board, hold it
against the axle.
i. Rotate the wheeled board halfway around the axle of the big wheels
and place the chassis on 4 wheels.
j. Push the swivel wheel in the holder underneath
the wheeled board. You will hear a 'click'
when the wheel is attached properly.
Note Do not fit the swivel wheel to the wrong
side of the wheeled board.
2 folding up the wheeled board
a. Fasten the elastic band's Velcro strap to the central bar.
b. Place the hook in the recess on the wheeled board.
c. Pull the elastic band and fasten it in place with the release catch. The
wheeled board is now folded up.
Note Remove the wheeled board by following the above instructions in
reverse order.
eng
5
