bühler
Allied Front-End Loader
- 33 - P4094
2595 – 2595 S – 2596 – 2596 S
Main Frame Assembly
Item Part No. Description 2595 2595 S 2596 2596 S
1 25050 2595 Main Frame Weldment 1 - - -
1 25051 2595 S Main Frame Weldment - 1 - -
1 25054 2596 Main Frame Weldment - - 1 -
1 25055 2596 S Main Frame Weldment - - - 1
2 25083 2595 Quick Attach Weldment 1 1 - -
2 25067 2596 Quick Attach Weldment - - 1 1
3 Ref. Lift Cylinder (see cylinder assembly) 2 2 2 2
4 Ref. Bucket Cylinder (see cylinder assembly) 2 2 2 2
5 114821 Pin Weldment 7.75 LG. (Quick Attach) 2 2 - -
5 114823 Pin Weldment 10.75 LG. (Quick Attach) - - 2 2
6 25045 Upright Weldment Right 1 1 1 1
7 25044 Upright Weldment Left 1 1 1 1
8 114835 Pin Weldment (Upright) 2 2 2 2
9 114804 Lift Lock 2 2 2 2
10 812717 Grommet 2 2 2 2
11 115882 Link Weldment 14.63" 4 4 4 4
12 115192 Link Weldment 10.25" 4 4 4 4
13 114810 Link Spacer 2.375 OD x 2.0 LG. 2 2 2 2
14 114475 Stand Tube 2 2 2 2
15 114303 Stand Foot 2 2 2 2
16 115902 Pin 1.25 x 5.75 8 8 8 8
17 115900 Pin 1.25 x 5.25 4 4 4 4
18 115898 Pin 1.25 x 4.25 4 4 4 4
19 113578 Bushing 1.25 ID x 1.63 OD x 1.375 LG 12 12 12 12
20 115021 Bushing 1.25 ID x 1.63 OD x 0.5 LG. 8 8 8 8
21 12779 Hair Pin Clip 6 6 6 6
22 110907 Stand Pin 2 2 2 2
23 81669 Hex Bolt 0.625 DIA x 3.5 LG. 2 2 2 2
24 81967 Nut Lock 0.625 DIA 2 2 2 2
25 81344 Nut Lock (Nylon) 0.375 NC 4 4 4 4
26 81570 Flat Washer 0.375 DIA 4 4 4 4
27 24242 Cross Tube Cover 1 1 1 1
28 81592 Nut Hex 0.375 NC GR2 PL 4 4 4 4
29 81637 Lock Washer 0.50 DIA 2 2 2 2
30 813228 Wing Nut 0.50 DIA 2 2 2 2
31 115909 Pin Cap 15 15 15 15
32 81615 Washer Lock 0.438 DIA 16 16 16 16
33 81597 Hex Bolt 0.438 DIA x 1.00 GR5 PL 16 16 16 16
34 115298 Leveling Rod 1 1 1 1
35 115813 Leveling Rod Guide 1 1 1 1
