bühler
Allied Front-End Loader
- 37 - P4094
2595 TSL – 2595 S TSL – 2596 TSL – 2596 S TSL
Main Frame Assembly
Item Part No. Description 2595 TSL 2595 S TSL 2596 TSL 2596 S TSL
1 25052 2595 TSL Main Frame Weldment 1 - - -
1 25053 2595 S TSL Main Frame Weldment - 1 - -
1 25056 2596 TSL Main Frame Weldment - - 1 -
1 25057 2596 S TSL Main Frame Weldment - - - 1
2 25083 2595 Quick Attach Weldment 1 1 - -
2 25067 2596 Quick Attach Weldment - - 1 1
3 Ref. Lift Cylinder (see cylinder assembly) 2 2 2 2
4 Ref. Bucket Cylinder (see cylinder assembly) 2 2 2 2
5 114821 Pin Weldment 7.75 LG. (Quick Attach) 2 2 - -
5 114823 Pin Weldment 10.75 LG. (Quick Attach) - - 2 2
6 25073 Upright Weldment Right (TSL) 1 1 1 1
7 25072 Upright Weldment Left (TSL) 1 1 1 1
8 114835 Pin Weldment (Upright) 2 2 2 2
9 115884 Pivot Plate 2 2 2 2
10 114805 Leveling Tube Weldment 2 - 2 -
10 114863 Leveling Tube Weldment (Short) - 2 - 2
11 114804 Lift Lock 2 2 2 2
12 812717 Grommet 2 2 2 2
13 115882 Link Weldment 14.63" 4 4 4 4
14 115192 Link Weldment 10.25" 4 4 4 4
15 114810 Link Spacer 2.375 OD x 2.0 LG. 2 2 2 2
16 114475 Stand Tube 2 2 2 2
17 114303 Stand Foot 2 2 2 2
18 115902 Pin 1.25 x 5.75 16 16 16 16
19 115900 Pin 1.25 x 5.25 4 4 4 4
20 115898 Pin 1.25 x 4.25 2 2 2 2
21 113578 Bushing 1.25 ID x 1.63 OD x 1.375 LG 24 24 24 24
22 115021 Bushing 1.25 ID x 1.63 OD x 0.5 LG. 8 8 8 8
23 12779 Hair Pin Clip 6 6 6 6
24 110907 Stand Pin 2 2 2 2
25 81669 Hex Bolt 0.625 DIA x 3.5 LG. 2 2 2 2
26 81967 Nut Lock 0.625 DIA 2 2 2 2
27 81344 Nut Lock (Nylon) 0.375 NC 4 4 4 4
28 81570 Flat Washer 0.375 DIA 4 4 4 4
29 24242 Cross Tube Cover 1 1 1 1
30 81592 Nut Hex 0.375 NC GR2 PL 4 4 4 4
31 81637 Lock Washer 0.50 DIA 2 2 2 2
32 813228 Wing Nut 0.50 DIA 2 2 2 2
33 115909 Pin Cap 22 22 22 22
34 81615 Washer Lock 0.438 DIA 22 22 22 22
35 81597 Hex Bolt 0.438 DIA x 1.00 GR5 PL 22 22 22 22
36 115298 Leveling Rod Weldment 1 1 1 1
37 81966 Nut Lock (Nylon) 0.50 NC 2 2 2 2
38 114969 Guide Bracket 1 1 1 1
39 115012 U-Bolt 1 1 1 1
