6-64
Removing the Rear Seat Cushion
NOTICE:
The battery and main fuse boxes are located under
the rear seat cushion. The battery’s ground
terminal and some relay wires are exposed. To help
avoid damage to the battery and wires, be careful
when removing or reinstalling the seat cushion. Do
not remove covers from covered parts. Do not store
anything under the seat, as objects could touch
exposed wires and cause a short.
To remove the rear seat cushion:
1. Pull up on the front of the cushion to release the
front hooks.
2. Pull the cushion up and out toward the front
of the vehicle.
To reinstall the rear seat cushion:
