10-64 Vehicle Care
Storing the Flat Tire
1. Cable
2. Liftgate Hinges
3. Spare Tire Heat Shield
4. Center of the Wheel
5. Door Striker
1. Remove the cable package from
the jack storage area.
2. Remove the small center cap by
tapping the back of the cap with
the extension of the shaft, if the
vehicle has aluminum wheels.
3. Put the flat tire in the rear
storage area with the valve stem
pointing toward the rear of the
vehicle.
4. Pull the cable (1) through the
door striker (5), the center of the
wheel (4), and the plastic spare
tire heat shield (3), as shown.
5. Hook the cable onto the outside
portion of the liftgate hinges (2).
6. Hook the other end of the cable
onto the outside portion of the
liftgate hinge on the other side of
the vehicle.
7. Pull on the cable to make sure it
is secure.
8. Make sure the metal tube is
centered at the striker. Push the
tube toward the front of the
vehicle.
9. Close the liftgate and make sure
it is latched properly.
