Escalade hybrid vs. the Competition
BOLD denotes an XLR advantage.
2010 Cadillac 2010 Lexus
Escalade 4x4 RX 450h AWD
Hybrid Hybrid
Performance Specifications
Base Engine 6.0L V8 3.5L V6
Horsepower @ rpm 332 @ 5100 245 @ 6000
Torque (lb.-ft.) @ rpm 367 @ 4100 234 @ 4800
Std. Transmission Two-mode 6-speed
4-speed auto. CVT
Drivetrain 4WD AWD
Suspension, front Ind. short-long-arm Independent,
struts coil-over-shock
Suspension, rear 5-link rigid axle, Ind. double
coil spring wishbone
Steering Type Electric-assist Electric-assist
rack and pinion rack and pinion
Towing Capacity (kg/lb.)
1
3,357/7,500 907/2,000
Fuel tank 98/21.6 65/14.3
Turning radius 5.95/19.5 5.7/18.7
Seating capacity 8 5
Dimensions and Interior Volume in mm/inches unless otherwise indicated
Wheelbase 2,946/116.0 2,740/107.9
Curb weight 2,795/6,161 2,110/4,651
Exterior length 5,144/202.5 4,770/187.8
Exterior body width 2,007/79.0 1,885/74.2
Exterior height 1,887/74.3 1,720/67.7
Front tread 1,732/68.2 1,630/64.2
Rear tread 1,702/67.0 1,620/63.8
Front legroom 1,049/41.3 1,096/43.1
Rear legroom 991/39.0 942/37.1
Third row legroom 650/25.6 NA
Front headroom 1,024/40.3 992/39.1
Rear headroom 996/39.2 958/37.7
Third row headroom 963/37.9 NA
Front hiproom 1,636/64.4 1,412/55.6
Rear hiproom 1,539/60.6 1,384/54.5
Third row hiproom 1,539/60.6 NA
Front shoulder room 1,659/65.3 1,472/58.0
Rear shoulder room 1,656/65.2 1,462/57.6
Third row shoulder room 1,567/61.7 NA
Luggage volume 479/16.9 1,133/40.0
Luggage volume (max) 3,084/108.3 2,274/80.3
Passenger volume 4,871/172.0 2,823/99.7
Vehicle Features
Active Fuel Management Std. NA
Adaptive suspension Std. NA
Limited slip differential Locking NA
Remote vehicle start Std. NA
Navigation system Std. Opt.
OnStar
®
Std. NA
Power liftgate Std. NA
Side Blind Zone Alert Std. NA
Rearview camera Std. Std
Heated rear seats Std. NA
Standard wheels 22-inch 18-inch
Surround sound audio Std. NA
Rear audio controls Std. NA
Battery rundown protection Std. NA
Powertrain warranty
(yrs/km)
60/160,000 72/110,000
Hybrid component warranty 96/160,000 96/160,000
1. When properly equipped.
5 Keys to Learning
Comfort and Convenience
– Standard 12-way power adjustable heated and cooled front
seats with driver memory
–
IntelliBeam
– Bose 5.1 Digital Surround Sound System
– XM Satellite Radio
– Available DVD rear-seat entertainment system
– Remote Vehicle Starter System
– Standard Bluetooth
®
hands-free phone interface
– Power liftgate
Power and Performance
– Two-mode Hybrid system is a patented hybrid technology with
two modes optimized for city and highway driving
First mode: At low speed and light loads, the vehicle can oper
-
ate by electric power or engine power, or any combination
Second mode: Primarily for highway speeds and heavy loads,
providing electric assist or full V8 power when needed.
– 300-volt Energy Storage System works with electric motors in
the transmission to produce electric power
– Regenerative braking captures some of the energy lost during
vehicle braking and coasting and returns it to the battery for
future use
– Hybrid status information is displayed on the navigation
screen
– Standard all-wheel drive
– Towing up to 2,540 kg (5,600 lb.)
1
Ride and Handling
– Magnetic Ride Control suspension
– Automatic rear load leveling
–
Standard 22-inch chrome wheels
Quality, Durability and Reliability
– 4-year/80,000-km New Vehicle Limited warranty
– 5-year/160,000-km powertrain component warranty
–
8-year/160,000-km hybrid-specific component warranty
Safety and Security
– Dual-stage frontal air bags, front seat side-impact thorax air
bags and head curtain side-impact air bags for all rows with
rollover sensors
2
– Side Blind Zone Alert
– StabiliTrak with Proactive Roll Avoidance
2. Always use safety belts and proper child restraints, even with air bags. Children are safer when
properly secured in a rear seat. See Owner Manual for more safety information.
2010 Escalade
Hybrid
Quick Facts
• Walkaround Summary
• Competitive Comparison
• 5 Keys to Learning
Additional copies can be obtained by printing PDF file from LMS or Global Connect
All information contained in this pocket piece is based on the latest information available as of
12/2009. Cadillac and General Motors of Canada reserve the right to discontinue or change at any
time, without notice, any prices, colours, parts, materials, standard equipment, optional equipment,
Marketing Option Packages, special equipment, specifications and/or body types and models. This
material is not legally approved for use in any advertising. It is intended for use by dealership em-
ployees only and is not to be disseminated to, or reviewed by, consumers. Copyright 2009 by General
Motors. Produced by GMPRO for VSSM Product Training.
