Vehicle Care 10-31
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
Fuses Usage
A/C CLTCH Air Conditioning
Clutch
ABS MTR Antilock Brake
System (ABS)
Motor
AFS Adaptive Forward
Lighting System
AIRBAG Airbag System
AUX POWER Auxiliary Power
AUX
VAC PUMP
Auxiliary
Vacuum Pump
AWD All-Wheel-Drive
System
BATT 1 Battery 1
BATT 2 Battery 2
BATT 3 Battery 3
CIGAR
LIGHTER
Cigarette Lighter
Fuses Usage
ECM 1 Engine Control
Module 1
ECM/
FPM IGN
Engine Control
Module/Fuel Pump
Control Module
Ignition
EMISSION 1 Emission 1
EMISSION 2 Emission 2
EVEN COILS Even Injector Coils
FAN 1 Cooling Fan 1
FAN 2 Cooling Fan 2
* Headlamp Washer
(China)/Trailer
Brake
FPM Fuel Pump Power
Module
FOG
LAMP (GMC)
Fog Lamps (GMC)
HTD
STR WHL
Heated Steering
Wheel
HORN Horn
Fuses Usage
HTD MIR Heated Outside
Rearview Mirror
HUMIDITY/
MAF
Humidity Sensor/
MAF Sensor
HVAC BLWR Heating,
Ventilation, and Air
Conditioning
Blower
LT HI BEAM Left High-Beam
Headlamp
LT LO BEAM Left Low-Beam
Headlamp
LT PRK Left Parking Lamp
LT TRLR
STOP/TRN
Trailer Left
Stoplamp and Turn
Signal
ODD COILS Odd Injector Coils
PWR L/GATE Power Liftgate
PWR
OUTLET
Power Outlet
RR APO Rear Accessory
Power Outlet
