Fuses Usage
5
Engine Control Module
(ECM)/Transmission Control
Module (TCM)
6 Memory Module
7 Not Used
8 Steering Wheel Illumination
9 Front Heated/Cooled Seat Module
10
Run 2 - Heated/Cooled Seats,
Heated Washer Fluid
11 Not Used
12 RPA Module
13 PASS-Key
®
III System
14 Unlock/Lock Module
15 Magnetic Ride Control
16 Daytime Running Lamps (DRL)
17 Sunroof
18 Body Control Module (BCM) Dim
19 Body Control Module (BCM)
20 Run 1-Heated Steering Wheel
Fuses Usage
21 Ignition Switch
22 Driver Door Module
23 Not Used
24 Electronic Leveling Control Module
25
Body Control Module
(Left Turn Signal)
26
Cigarette Lighter, Auxiliary Power
Outlet
27 Not Used
28 Retained Accessory Power 1 (RAP)
29 Passenger Door Module
30 Sensing and Diagnostic Module
31 Accessory Power Outlets
32
Body Control Module (BCM)
(Inadvertent)
33 Retained Accessory Power 2 (RAP)
34 CanisterVent Solenoid
35 Body Control Module (Courtesy)
36
Body Control Module
(Right Turn Signal)
5-107
