Bullard Eclipse - Page 5

10 1/4"
1 15/16"
1 13/16"
5/16"
4X #25 (.1495) DRILL
+.005
-.000
Figure 3
NOTE
When printing this template, make sure
the Page Scaling is set to NONE on your
print dialogue box.
Also measure the template to make sure
it has printed with the correct dimensions
before drilling holes.
