BullFrog A8L - M Series Wiring Diagrams (North America)

52
Model STIL7, STIL7-E
7′-4″ (2.24m) x 7′ (2.13m) x 34″ (.86m)
85” [216cm]
From bottom of base
81.1” [206cm]
From bottom
of base
32.7”
[83cm]
32.7”
[83cm]
27.2”
[69cm]
12”
[30.5cm]
6”
[15cm]
3”
[7.6cm]
Model STIL5, STIL5-E
6′-10″ (2.08m) x 5′-7″ (1.69m) x
31″ (.79m)
78.4” [200cm]
From bottom of base
13.7” [35cm]
62.9”
[160cm]
From bottom
of base
17.5” [45cm]
3” [8cm]
15” [38cm]
6.4” [16cm]
9.6” [24cm]
Model X6R, X6R-E
6’7” (2.01m) x 6’7” (2.01m) x
36” (.91m)
21” [53cm]
78”
[198cm]
39”
[99cm]
18.1
46
31.6
80
Model A5L, A5L-E, R5L,
R5L-E, X5L, X5L-E
5'8" (1.73m) x 7' (2.03m) x
31" (.79m)
80.2” [204cm]
From bottom of base
63.2”
[161cm]
From bottom
of base
5”
[13cm]
5”
[13cm]
3”
[8cm]
15.3”
[39cm]
