Page 7For technical questions, please call 1-888-866-5797.Item 64945 64946
Parts List and Diagram
Part Description Qty
1 Lampshade 2
2 Seal Ring 2
3 M4*10 Screw 2
4 Socket 2
5 Lamp Housing 2
6 Hinge Pad 2
7 Hinge Knob 2
Part Description Qty
8 Bolt Cover 1
9 Hinge 2
10 Mounting Bolt 1
11 Ring 2
12 Gasket 1
13 Wire Nut 1
14 Wire Nut 1
Part Description Qty
15 Screw 2
16 Mounting Plate 1
17 Green Screw 1
18 Main Housing 1
19 Sensor 1
20
Temporary Hanger
(not shown)
1
Record Serial Number Here:
Note: If product has no serial number,
record month and year of purchase instead.
Note: Some parts are listed and shown for
illustration purposes only, and are not available
individually as replacement parts. Parts may not be
interchangeable. Specify item number when ordering.
