Specifications
Supports: SMPTE 292M/259M (NTSC 480i;
PAL 576i; 720p59.94; 1080i50/59.94; 1080p30)
Level: 800mv p-p
Impedance: 75 ohm terminating
Equalization: Automatic up to 100m @ 1.5GHz
using Belden 1694
Output Jitter: 0.2UI (expected)
Inputs Number: 1
Connectors: BNC
Level: 20-800mV p-p
Freq. Range: 143Mbps to 1.5Gbps
Impedance: Hi-Z
Outputs
HDA4: 4 (BNC)
HDSR: 2 (BNC)
Level: 800mV p-p, Unity Gain
Processing: Re-clocked outputs
Freq. Range: 143Mbps to 1.5Gbps
Impedance: 75 ohm
Front Panel Control Functions:
• Switch 1: Power ON/OFF
• Switch 2: Bypass/Reclocked
Indicators:
• Number: 1
• Signal present: LOCK (LED)
Size: 4.2 W x 1.5 H x 5.5 D inches.
Power: 5VDC (included): 120 VAC 60 Hz, 5 Vdc
0.5 A, UL Listed
Environmental:
• Operation temperature: 0C to +40C
• Storage temperature: -40C to +85C
• Relative Humidity: 5% to 95% (non-
condensing)
Warranty: 2-Year Parts and Labor
HDA4 & HDSR HD/SD SDI Distribution Amplifiers 4
