Gas conversion
Caution : The following procedures must be
undertaken by authorized service people.
Your appliance is adjusted to be operated with
LPG/NG gas. The gas burners can be adapted to
different types of gas, by replacing the
corresponding injectors and adjusting the
minimum flame length, suitable to the gas in use.
For this purpose, the following steps should be
performed
Hob Burners
Cut off the main gas supply and unplug from the
electric mains
Remove the burner cap and the adapter
(Figure 7).
Unscrew the injectors. For this, use a 7mm
spanner(Figure 8).
Replace the injector with the ones from the gas
conversion kit, with corresponding diameters
suitable to the type of gas that is going to be
used, according to the information chart (which
is also supplied in the gas conversion kit).
:
Changing injectors:
:
•
.
•
•
•
Figure 8
Injector
Spanner
Figure 7
Oven/Grill Injectors:
To replace the oven injector, open the oven door.
Dismount the burner cover by removing the
screws (Figure 9.1). Remove the screws which
fasten the burner to the lower side of the inner
case (Figure 9.2) and turn the burner carefully to
yourself (Figure 9.3). Remove the oven back panel
and the oven injector should be visible and can be
replaced from the back side with M6 spanner
(Figure 9.4).
To replace the grill injector, open the oven door
and remove the screws which are fastened to the
grill burner top side of the inner case (Figure 9.5.).
Pull the grill burner carefully to yourself. The grill
injector will appear from the side where the burner
was disassembled (Figure 9.6).
Remove the injectors with a 7mm spanner and
replace the injector with the ones from the spare
set, with corresponding diameters suitable to the
type of gas that is going to be used, according to
the information chart (which is also supplied in the
gas conversion kit).
After conversion is completed, check for any gas
leakages.
