Installation
IMPORTANT - Electrical connections must be
carried out by a suitably qualified person and in
accordance with all relevant local building and
installation regulations.
Electrical connections
1. This appliance is fitted with fused plug which
should be inserted into a suitable mains
socket.
2. It is recommended that the mains socket is
located behind the appliance and is switched
on and off via a separate switched Fused
Connection Unit (FCU).
3. It is recommended that the switched FCU is
located adjacent to the appliance within a
maximum distance of 2m. The switched FCU
must not be located above the appliance but
should be easily accessible in case of an
emergency.
7
Positioning & electrical connection
Customer Helpline 0345 257 7271
L
N
BROWN
YELLOW+GREEN
BLUE
Electrical connection diagram
Figure 3
