6. Remove the levelling feet from anotherside of the
unit boom and transfer it to the corresponding posion
on the opposite side of the unit boom.
7. Reaach the boom screws, boom hinge and
levelling feet to the opposite side of the unit boom.
Loosely secure.
8. Carefully set the door back into place.Install the
upper hinge and screws. Ensure the door is aligned
horizontally and vercally so that the seals are
closed on all sides before finally ghtening the upper
hinge.Use a spanner to ghten it if necessary.
9. Put the top cover back and fix it in place with the screws.
10. With the door closed, check that the door is aligned
horizontally and vertically and that the seals are closed on
all sides before finally tightening the bottom hinge.
Re-adjust the levelling feet as needed.
20
screw
screw
