Item Model J11100 Model J11200 Description Qty.
1 125-6-1103-102 135-6-1103-100 Saddle 1
2 A24-6-4302-107 430-6-4302-406 Retaining Ring 1
3 125-6-1808-100 226-6-1808-106 Retaining Ring 1
4 * * O-ring 1
5 125-6-1204-108 135-6-1204-106 Dust Seal 1
6 * * O-ring 1
7 N/A N/A Ram Plunger 1
8 125-6-1209-108 135-6-1209-106 Ram Bearing 1
9 * * Back-up Ring 1
10 * * U-cup 1
11 N/A N/A Base Assy. 1
12 505-9-0092-207 505-9-0092-207 Oil Filler Plug 1
13 238-6-1701-403 238-6-1701-403 Release Valve 1
14 * * Oil Seal 1
15 511-2-0052-001 512-2-0052-008 Spring 1
16 115-6-1603-104 115-6-1603-104 Screw 1
17 * * O-ring 1
18 * * Back-up Ring 1
19 125-6-1306-106 125-6-1306-106 Pump Piston 1
20 518-4-0080-016 518-4-0080-016 Pin 2
21 125-4-1300-102 125-4-1300-102 Handle Sleeve 1
22 677-5-0070-101 677-5-0070-101 “E” Clip 2
23 125-4-2100-109 135-4-2100-107 Handle 1
24 601-7-0006-005 601-7-0006-005 Steel Ball 2
25 511-2-0048-000 511-2-0048-000 Spring 1
26 * * Gasket 1
27 649-1-0080-027 649-1-0080-027 Socket Head Bolt 1
28 509-9-0145-109 509-9-0145-109 Safety Valve Cap 2
29 414-6-1215-307 414-6-1215-307 Safety Valve Screw 1
30 * * O-ring 1
31 512-2-0067-010 512-2-0067-010 Spring 1
32 414-6-1216-107 414-6-1216-107 Needle 1
(*) 125-3-9901-102 135-3-9901-100 Repair Kit -
7
(*) - Indicates items included in, and available only as part of Repair Kit.
N/A - Part is not available as replacement.
Mini Jacks
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-448-2142
E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com
MODELS: J11100 &J11200
Parts List
Note: Not all components of the jack are replacement items, but are illustrated as a convenient
reference of location and position in the assembly sequence.
