C-LOGIC 8500 User Manual

Three-phase active power (W)
Escala Precisión Resolución
3kVA ±(3%+5) 0.001kVA
12kVA ±(3%+5) 0.01kVA
30kVA ±(3%+5) 0.01kVA
120kVA ±(3%+5) 0.1kVA
150kVA ±(3%+5) 0.1kVA
600kVA ±(3%+5) 0.1kVA
Minimum test current: 2A; Minimum test voltage: 50V
Power factor
Escala Precisión Resolución
0.3~1
Capacitivo
±(0.02%+2)
0.001
0.3~1
Inductivo
±(0.02%+2)
0.001
Minimum test current: 2A; Minimum test voltage: 50V
Reactive power
Escala Precisión Resolución
3kVAr ±(3%+5) 0.001kVAr
12kVAr ±(3%+5) 0.01kVAr
30kVAr ±(3%+5) 0.01kVAr
120kVAr ±(3%+5) 0.1kVAr
150kVAr ±(3%+5) 0.1kVAr
600kVAr ±(3%+5) 0.1kVAr
Minimum test current: 2A; Minimum test voltage: 50V. The
reactive power is calculated according to the measured
values of V, A and kW.
AC RMS voltage
Escala Precisión Resolución Impedancia de
entrada
80V ±(1%+5) 0.1V
1 MΩ // 10 pF
180V
±(1%+5)
0.01V
400V
±(1%+5)
1V
600V ±(1%+5) 1V
Maximum allowed overload voltage: 750V (RMS)
AC RMS current
Escala Precisión Resolución
20A ±(2%+5) 0.01A
40A ±(2%+5) 0.01A
100A ±(2%+5) 0.1A
200A ±(2%+5) 0.1A
450A ±(2%+5) 1A
1000A ±(2%+5) 1A
Maximum allowed overload current: 1200A
Single phase active power (W)
Escala Precisión Resolución
30kW ±(3%+5) 0.01kW
60kW ±(3%+5) 0.01kW
120kW ±(3%+5) 0.1kW
150kW ±(3%+5) 0.1kW
300kW ±(3%+5) 0.1kW
600kW ±(3%+5) 0.1kW
Minimum test current: 2A; Minimum test voltage: 50V
