Cabasse SA - 210, rue René Descartes - BP 10 - 29280 Plouzané - France
Tel +33 (0)2 98 05 88 88 - Fax +33 (0)2 98 05 88 99
www.c abasse.com
Use in ceiling / in wall
Ways 2
Drivers
2 x DOM24 tweeter on a rotating base
soft dome membrane
1 x 17T15 IC midrange-woofer
P2C diaphragm
Cross-over point 3,200 Hz
Frequency response 40 Hz - 19,000 Hz
Sensitivity 1 W / 1 m 84 dB
Nominal impedance 8 ohms
Minimum Impedance 6.4 ohms
Power handling 2 x 20 W
Peak power 2 x 160 W
Dimensions (H x W x D) 24 x 24 x 9.7 cm - 9.4 x 9.4 x 3.8 in
Weight 1.5 kg - 3.3 lbs
Standard finish white (paintable grill)
ARCHIPEL 17ICPS
97 mm (3.8in)
197 mm (7.7in)
240 mm (9.4in)
91,5 mm (3.6in)240 mm (9.4in)
41 mm (1.6in)
