28
ON WALL MOUNT OF THE SOUND BAR
114
1045
79
45
The bracket being horizontal and
centered under the TV set, mark the
4 holes and install proper inserts.
Screw the bracket on the wall.
Position the buttons of the sound
bar above the notches.
Slide both buttons down to the end
of each notch.
