OWNER’S MANUAL
10
EN
1
2
AC230V/110V
AC230V/110V
Tuner DVB-T
3
3
5. Connect the coaxial cable to antenna covering the plug with
water resistant cap.
1. F-type connector 2. Cable 3. Water resistant cap
6. Mounting:
• Mounting 1: Direct connection to TV
• Mounting 2: Connection via DVB-T TV set top box
1
2
AC230V/110V
AC230V/110V
Tuner DVB-T
3
3
1
2
AC230V/110V
AC230V/110V
Tuner DVB-T
3
3
Note: Once the mounting is done, make sure to position the
antenna in an optimum spot for signal reception, and then screw
the holder tight.
For better reception, check:
1. Whether antenna is away from interference sources: do not
place antenna near large electrical appliances, such as air
conditioner, elevator, hair dryer, microwave oven, etc.
2. When using indoor, place it near a window.
DVB-T TV set top box
To Next Page
