Package contents:
1. The main frame of the cart
2. Two main wheels, front wheel
3. Umbrella holder
4. Drink holder
5. This user manual
6. Tools for adjustment
In case any of above item is missing or damaged, please call
800-906-6918
or email
caddytek@gmail.com
to report.
Parts identification:
A: TPE handle grip
B: Umbrella holder
C. Umbrella holder base
D: Scorecard holder assembly
E: Basket with cooler
F: Handle frame
G: Upper bag holder bracket assembly
H: Handle height adjusting knob assembly
I: Main frame
J: Front connection Rod
J1: Main connection Rod
K: Leg frame bracket
L: 2 holes right leg frame
L1: 2 holes left leg frame
M: 4 holes right leg frame
N: Lower bag holder bracket assembly
O: Weight stabilizer
P: Supporting cable
Q: Main lower frame tube
R: Right wheel lock mechanism
R1: Left wheel lock mechanism
S: Rear wheel assembly
T: Lower bag holder bracket
U: Front wheel assembly
V: Foot brake assembly
W: Handle mesh net
