6-22
Then, without shutting off the engine, follow
these steps:
The transaxle fluid cap
is located next to the
radiator hose and
below the engine air
cleaner/filter assembly
on the driver’s side of
the engine. See “Engine
Compartment
Overview” in the Index
for more information
on location.
1. After removing the air cleaner/filter assembly to
reach the transaxle fluid cap, turn the cap
counterclockwise to remove. Pull out the dipstick
and wipe it with a clean rag or paper towel.
2. Push it back in all the way, wait three seconds and
then pull it back out again.
3. Check both sides of the dipstick, and read the
lower level. The fluid level must be in the
cross-hatched area.
4. If the fluid level is in the acceptable range, push
the dipstick back in all the way and turn the
handle clockwise. Reinstall the engine air
cleaner/filter assembly.
