Midgate Drain Grate Removal and
Cleaning
The midgate drain grate is located near the base of the
midgate in the cargo area. You will find a removable
drain grate covering the drain.
After hauling dirt, wood chips, pebbles etc. you will
need to flush the midgate drain with water. But first
you will have to remove the drain grate by using
the following steps:
1. Lower the midgate. See Midgate
®
on page 2-11
for more information.
2. Pull up on the rear side of the drain grate.
3. Tilt the drain grate away from you and pull it
straight out.
Reverse the procedure to reinstall the drain grate.
2-71
