Cadillac 2010 SRX - High Intensity Discharge (HID); Headlamps

Black plate (35,1)
Cadillac SRX Owner Manual - 2010
Vehicle Care 9-35
High Intensity Discharge
(HID) Lighting
{
WARNING
The low beam high intensity
discharge lighting system
operates at a very high voltage.
If you try to service any of the
system components, you could be
seriously injured. Have your
dealer or a qualified technician
service them.
The up‐level vehicle has HID
headlamps. After an HID headlamp
bulb has been replaced, the beam
might be a slightly different shade
than it was originally. This is normal.
Headlamps
Base Headlamp Assembly
(Front View Passenger Side)
A. Low‐Beam Headlamp/Daytime
Running Lamp (DRL)
B. High‐Beam Headlamp
C. Turn Signal Lamp
Base Headlamp Assembly
(Rear View Passenger Side)
A. Low‐Beam Headlamp/Daytime
Running Lamp (DRL)
B. High‐Beam Headlamp
C. Turn Signal Lamp
