Cadillac Escalade EXT Owner Manual - 2012
10-40 Vehicle Care
Fuses Usage
54
Automatic Level
Control
Compressor Relay
55
Climate Controls
(Ignition)
56
Engine Control
Module, Secondary
Fuel Pump
(Ignition)
J-Case
Fuses
Usage
57 Cooling Fan 1
58
Automatic Level
Control
Compressor
59
Heavy Duty
Antilock Brake
System
60 Cooling Fan 2
61
Antilock Brake
System 1
J-Case
Fuses
Usage
62 Starter
63
Stud 2
(Trailer Brakes)
64
Left Bussed
Electrical Center 1
65
Electric Running
Boards
66 Not Used
67 Transfer Case
68
Stud 1 (Trailer
Connector Battery
Power)
69
Mid-Bussed
Electrical Center 1
70
Climate Control
Blower
71
Power Liftgate
Module
72
Left Bussed
Electrical Center 2
Relays Usage
FAN HI
Cooling Fan High
Speed
FAN LO
Cooling Fan Low
Speed
FAN CNTRL
Cooling Fan
Control
HDLP
LO/HID
Low-Beam
Headlamp
FOG LAMP Front Fog Lamps
A/C
CMPRSR
Air Conditioning
Compressor
STRTR Starter
PWR/TRN Powertrain
FUEL PMP Fuel Pump
PRK LAMP Parking Lamps
REAR
DEFOG
Rear Defogger
RUN/CRNK Switched Power
