CALEFFI Z-one ZVR103 User Manual

47
Sequence of Operation / Settings
• Master / Slave switch: Master
• Pump Exercise: OFF
• Priority: OFF
• AUX During Priority Demand: OFF
• Sec Pump Status During Zone 1 Demand
Jumper: OFF
• System Pump Status During Zone 1 Demand
Jumper: ON
• A demand occurs from a thermostat on zones
2-6closingRtoW.The“T-STATCALL”LED
illuminates for the corresponding zone.
• ZVR control sends 24 VAC to the corresponding
zone MOTOR terminals to open the zone
valve.
• When the zone valve end switch closes,
the “VALVE OPEN” LED illuminates for the
corresponding zone. ZVR control sends
120 VAC to SYSTEM PUMP and SEC PUMP
outputs. The control will close the XX contacts
to signal the boiler of a demand.
• If a demand occurs from the thermostat on
zone1closingRtoW.The“T-STATCALL”LED
and the “VALVE OPEN” LED will illuminate.
(When using a pump for zone 1 instead of a
zone valve a jumper must be installed on the
ZONE 1 END SWITCH terminals.) ZVR control
sends 120 VAC to the ZONE #1 PUMP.
• When the thermostat demands from zones 2-6
are satisfied R to W will open and the “T-STAT
CALL”and“VALVEOPEN”LEDswillturnoff.
24 VAC is dropped to the corresponding zone
MOTOR terminals.
Description of terminals
= Ground
N = Neutral (Common leg of 120 VAC)
L = Line (Hot leg of 120 VAC)
Thermostat terminals
R = 24 VAC
W = Heat call
C = Common of 24 VAC
Boiler terminals
XX = Dry contact rated up to 120 VAC, 2 Amps,
which is typically connected to TT on boiler control,
closes when any zone calls including priority.
ZONE 1 E/S = Dry contact rated up to 120 VAC,
2 Amps, will close with any call to ZONE 1. Zone
1 can be enabled as a priority zone, typically used
for heating domestic hot water. The ZONE 1 E/S
can be used to close a DHW contact on boiler
controls equipped with these features.
AUX = Dry contact, rated up to 120 VAC, 2 Amps,
close when any zone calls and can be used as
signal to a variable speed self regulated pump or
other controls.
Pump terminals
SYSTEM PUMP = Runs when any zone calls for
heat.
SEC PUMP = Runs when any zone calls for heat.
ZONE 1 PUMP = Runs when zone 1 thermostat
calls for heat and zone 1 end switch has closed.
A jumper is required between the ZONE 1 END
SWITCH terminals when using a pump for ZONE
1 instead of a zone valve.
STATUS DURING ZONE 1 DEMAND ON / OFF:
When status jumper is placed on ON pins, the
secondary and / or system pump will continue to
operate during Zone 1 demand. When jumper is
placed on OFF pins, the corresponding pump will
be OFF during Zone 1 demand.
Valve terminals
Motor = 24 VAC to power the zone valve motor
End Switch = Connects to end switch on zone
valve. Must be jumped if using a 2–wire zone valve.
WARNING: NEVER CONNECT R & C DIRECTLY,
this will be a direct short on the 24 VAC supply
• If zone 1 thermostat is still calling for heat
the XX contacts will remain closed and the
SYSTEM PUMP and the ZONE #1 PUMP will
remain powered. 120 VAC will be dropped
to the SEC PUMP. (This is due to the jumper
position of the SEC PUMP for STATUS
DURING ZONE #1 DEMAND.)
• When all the thermostat demands are satisfied
RtoWwillopenandthe“T-STATCALL”and
“VALVE OPEN” LEDs will turn off.  The X X
contacts will open terminating the demand for
heat to the boiler. The 120 VAC is dropped to
all of the PUMP outputs (SYSTEM PUMP, SEC
PUMP and ZONE #1 PUMP).
