Connectiondiagram BordControl811 Art.-Nr.H08012081101
CALIRAElectronicGmbH&Co.KGLerchenfeldstraße987600Kaufbeuren-Neugablonz
BordControl811
Hauptschalter
12V
16A 10A 7A 7A
I II III
MadeinGermany
0
5pole
TankIIWaterpump
Pump+1,5mm²
(Wastewater)
BN¾
5
GY0
GN½
YE¼
WH1
Tank
0
12
10
16
14
1/4
0
1/2
3/4
1/1
B5108056502
MadeinGermany
Battery12VTankI Battery12V
(start)
(supply)
0,25mm²RD
0,25mm²BU
0,25mm²PK
2A
20A
2A
20A
atleast2,5mm²
(Freshwater)
Connection
plug
Fusesmustbeassembledneartothe
+polesofthebatteries
5pole3pole
5
max. max. 7A 7A
+ +
max.
16A
***
max.
10A
+
Electriclinesmustbecorrectdimensionedtoavoidvoltagedrops
andoverload. Thelengthofthelineandthecurrentareimportant
factorstodeterminetherightwirecrosssection.
Useatleastthevaluesofthefollowingrecommendations.
Wirecrosssectionrecommendations
Length
til1,5m
til3,0m
til6,0m
over6,0m
Current
til15/30Amp.
til15/30Amp
til15/30Amp
til15/30Amp
Wirecrosssection
1,5/4,0mm²
2,5/4,0mm²
4,0/6,0mm²
6,0/10,0mm²
Insertthesensorintotheholein
thetankandfastenitwithascrew
driver.Notethewirecolours. The
edgeoftherubbergasketis
pressedagainsttheoutersurface
ofthetank.Insidethetankitforms
arubberfold,whichsealsupthe
holesure.
Composethesensor,insertthe
screwwithsealingcompound
andfastensrewsfirstonlyby
hand.
Drillholeswith9,5-10,0mm
diameterintothewastewater
tank.
Burrtheholesfrombothsides.
