FRONT SERVICE PANEL
TOP VIEW
100 *740
1435
FRONT
SERVICE/CONTROL
PANEL
AIR
SAMPLING
POINT
AIR
INLET
650
*760
MAINS INLET
RCU STUBS
(If fitted)
482
406
WATER IN
WATER
OUT
L H SIDE
DISCHARGE
LIQUID
52
20
369
700
200
DRAIN
50
600
146
642 369
75*
OPTIONAL
AIR
OUTLET
REAR
VIEW
278 423
700
1435.00
960
AW/AC 1400/1800 VARIHEAT
NOTE: Dimensions marked * refer to dimensions of DUCT FLANGE KIT 50mm deep, available from Calorex
distributors. Inlet air filter kits also available.
OPTIONAL
AIR
OUTLET
REAR
VIEW
1030
730
496
188
MAINS INLET
580 565
L.H SIDE
80
1060
295496
1250
185
530
630
R.H. SIDE
161
40
50
LIQUID
DISCHARGE
RCU STUBS
(If fitted)
AIR OUTLET
L.H
SERVICE
PANEL
50
R.H
SERVICE
PANEL
FRONT
SERVICE
PANEL
700
*810
1550
100
*1380
1730
1030
AIR
SAMPLING
POINT
FRONT
SERVICE/CONTROL
PANEL
OPTIONAL FRONT ACCESS
AIR FILTER KIT OR DUCT
FLANGE KIT (50mm)
OPTIONAL SIDE ACCESS
AIR FILTER KIT (157mm)
NOTE: Dimensions marked * refer to dimensions of DUCT FLANGE KIT 50mm deep, available from Calorex
distributors. Dimensions are the same for the Front Access Inlet air filter kits, also available.
Alternative Side Access Inlet filter kit is 157mm deep.
AW/AC 4000 VARIHEAT
