CAMDEN CX-12 PLUS User Manual

Page 15 of 15
CX-12 PLUS DOOR INTERFACE RELAY INSTALLATION INSTRUCTIONS
FILENAME: CX-12PLUS-Diagram7.ai
DRAWING No: DRG-CX-12PLUS-07
CX-12PLUS Normally Locked Washroom Door Wiring Diagram
SCALE: NONE
DRAWN BY: DGW REVISED: 1/28/2020DATE: 11/16/09
5502 Timberlea Blvd.
Mississauga, Ontario
L4W 2T7
Outside Wall Switch
Inside Wall Switch
Magnetic Contact Switch
Inside ‘Push to Lock’ Switch
DRY2WET2DRY1WET1POWER
NO
NO
NC
NC
COM
COM
Relay2Relay1
CX-12 PLUS
CAMDEN DOOR CONTROLS
Fail-Secure Electric Strike (If Fail-Safe lock is used, wire to Terminals 4 & 5)
Wire MOV
(supplied)
directly to strike
or magnet
Power
for Strike
PUSH
TO
LOCK
N.C.
1 52 3 4 6 7 8 9 10 11 12 13 14 15 16
RL1 RL2
DOR
RL1
DOO
RL2
DOR
RL2
OFF / ON
1 2 3
MOV
+
-
12/24 V
AC/DC
Power
Door #2 Operator
