MULTIFUNCTION GAUGE (ANALOG/DIGITAL)
MESSAGE DESCRIPTION
BRAKE
Message displayed when the brakes are applied continuously for
15 seconds. (Spee d needs to be higher than 5 km/h (3 MPH))
NORMAL KEY
Displayed at power up wh en the normal key is used.
WORK KEY
Displayed at power up when the work key is used.
SEAT BELT
When the driver seat belt is not buckled and the vehicle speed
is less than 10 km/h (6 MPH), the message is displayed and the
pilot lam p will be lit. No eng ine torque limitation engage d.
ENGINE
LIMITATION
ENGAGED FASTEN
SEAT BELT
When the drive r seat be lt is not buckled and the ve hicle speed is
above 10 km/h (6 MPH), the message is displayed and the pilot
lamp stays on. The engine management will engage a torque
limitation that will limit the vehicle speed to approximately
20 km/h (12 MPH).
WORK MODE
ACTIVE
Displayed when work mode is activated.
NORMAL MODE
ACTIVE
Displayed when normal mode is activated
ECO MODE ACTIVE
Displayed when ECO mode is activated.
MAINTENANCE
REQUIRED
(1)
Displayed in gauge when vehicle is due for a maintenance.
LOW GEAR
Displayed when belt protection is active in high gear. (If available
and activated on your model)
(1)
To erase the MAINTENANCE RE-
QUIRED message, proceed as fol-
lows:
1. Select PARK.
2. Turn ignition switch to ON. Do NOT
start engine.
3. Set the cluster to odometer display.
4. Press SET button on the multifunc-
tion gauge and keep it pressed until
step 6.
5. Switch the high beam On-Off three
times rapidly.
6. Turn ignition switch to OFF.
NOTE: Steps 4 and 5 must be com-
pleted within 5 seconds.
NOTE: Do not turn ignition switch to
ON before the multifunction gauge
turns off.
7) Gearbox Position Indicator
Displays the selected gearbox range.
8) Secondary Digital Display
Displays useful real t ime information to
the rider. For display function informa-
tions, refer to
SET (S) BUTTON
.
9) Fuel Level Indicator
Bar graph that continuously indicates
the level of fuel left in the fuel tank.
10) Engine Temperature Indicator
Bar graph that continuously indicates
the engine coolant temperature.
11) Numerical Display
The vehicle speed or the engine revo-
lutions (RPM) can be displayed. See
MODE (M) BUTTON
in this section.
64
