CanDo HD Diagnostic Tablet
35
6
ISO 15765-4, CAN-BUS
high speed diagnostic line
(CAN-H line)
14
ISO15765-4, CAN-BUS high
speed diagnostic line
(CAN-L line)
7
KWP1281 or KWP2000
protocol diagnostic line (K
line)
15
KWP1281 or KWP2000
protocol diagnostic line (L
line)
8
Factory retained
16
Connect battery “+” pole
For more product introduction and help, please visit CANDO official website
www.candointl.com.
