SECURING THE COOKER TO WALL (g.16)
Note:- The installation of the chain provided is for
safety reasons, it must be installed as indicated
below.
.
To prevent the cooker tipping forwards in the event of
children standing on the oven door or where users put
extreme weight on the door when in open position, two
chains MUST BE xed to the back of the oven which
should at all times be secured to the threaded pins .
The threaded pins should be secured to the wall at the
back of the cooker.
Assembly instructions
• Secure threaded pins into wall immediately behind
and to the left-hand side about 770 mm from the oor.
Finished xing the chains must be stretched
INSTRUCTIONS FOR THE INSTALLER
16
