.22.
CCVB 60D UK
•
Height Adjustable:
863-883mm
o Your Wine Coolers can be used as a freestanding or a built in unit. The
clearances shown in the above drawing should be followed for both
types of installation.
o In particular, the depth dimension must be observed.
IMPORTANT: The vent at the base of the appliance is for ventilation. Nothing
should be placed in front of this vent; otherwise your Wine Cooler may not
operate properly.
o A decorative plinth can be tted to the front of the base vent as long as
the cut out shown in the diagram below is made in the plinth. This cut out
is required whether the vent is removed or not.
CCVB 15 UK
