08 GB
Selecting a zone
When zone is already ON a lower lighting intensity for the not selected
zones that are ON is produced.
If only one zone is ON, this zone is already selected by default, without
needing to short press (150 msec) over selection key.
Increase / Decrease power level
With a short press on ‘+’ or ‘-‘ keys, Increase or decrease power in the
selected zones digit: 0-1-2-3...9-P
1. For Long Presses in + or - keys, power level increases /decreases
continuously. With a fast increase, power stops at level 9, and for a
higher power another short press is needed on the + key. No beep
sound is heard with fast increase / decrease.
2. Once arrived to P power level, pressing + key again does not
change power level to 0.Once arrived to 0 power level, pressing - key
again does not change power level to P.
3. With a zone ON at 0 power level, if the zone is hot, 0 will blink
alternatively. After 10 seconds, 0 will disappear an ‘H’ letter will appear
fixed on display.
4. When a heater is selected and ‘+’ & ‘-‘keys are touched at the same
time, power level will go to ‘0’ but heater will maintain selected during
10 seconds. If heater was temporized, timer will go to Off. This action
can only be developed in several cases depending touch control
configuration.The following examples are for information only.
Personal experience should then let you adapt these settings to your
taste and habit
Child Lock option
This action will be done when ‘+’ & ‘-‘keys were touched at the same
time.
Then, any time when a key will be touched, displays will show "L"
during 2sec. heating remains at the same state.
To deactivate Child Lock, follow the same process explained before.
Then Short beep will be heard and displays will show "n" letter. Hob will
remain unlocked.
Note: An automatic child lock will produce in 15 minutes after total
Switch OFF of the hob.
To switch ON double extension ring, associated main zone must be
already ON and Indicating power level must be higher than 0.
8.1- Double zone ON
1st Short Press on extension key Switches ON extension ring. LED
over extension key turns ON if Extension ring is ON.
2nd Short Press on extension key Switches OFF extension ring.
Short beep each press on extension key.
8.2- Triple zone ON
1st Short Press on extension key Switches ON 1st extension ring. 1
LED over extension key turns ON if 1st extension ring is ON (left LED in
case of triple zone, middle and only LED in case of double zone) 2nd
Short Press on extension key Switches ON 2nd extension ring.
Double / Triple zones
Bridge function
The bridge can be enabled only when both heaters are off. One heater
of the bridge has been selected, to activate bridge function touch
bridge key.
Abeep sounds and the zone LED is switched on if the zone is enabled.
Both bridge heaters will be selected at the same time.
Once the heaters selected, if the power level is not the desired power
level, by the + - keys.
Both bridge heater displays will show same power level.
The function will finish:
- If the bridge key is touched in setting mode
- If user selects power level “0”
Overflow security
Something (an object or a liquid) is pressing any key during more than
5s. 2 Short Beep + 1 Long beep every 30s while the key is pressed.
Cook-top will turn Off. This symbol will maintain blinking while the
matter persist.
Timer
Timer function can be activated with its own key.
Select the zone to be timed. Power level of the zone greater than 0.
Static is displayed in the zone being timed . "0 0" in the digits
reserved for the timer.
1) With "+" or "-" keys, timer time can be chosen. No Beeps at time
change.
2) Pressing continuously timer key, the timer is cancelled (goes to 00).
3) If timer "+" or "-" keys is maintained pressed there is quick setting.
4) When setting timer time, it is possible to go from "00" to "99" with "-"
key, and from "99" to "00" with "+" key.
5) Maximum time 99 minutes.
2 LEDs over extensºon key turn ON ºf 1st and 2nd extensºon rºngs are
ON 3rd Short Press on extensºon key. Swºtches OFF 1st and 2nd
extensºon rºngs.
Short beep each press on extensºon key.
Residual Heat Indicator (In radiant heaters-> calculated)
The same indicators can be used for “residual heat” indication as well.
Atime table must be defined on this purpose: Rest Heat time=f (power
level, working time).
While a temperature on the cook top glass surface is above
65 Cb(theory value), this condition will be shown in the associated
o
display, by means of an “H”.
To generate a temperature above 65 C a heating element has to be in
o
operation for certain time, this time depends on the power level. Once
this time has expired, the residual heat warning will be shown when
the heating element is switched off.
6) When the tºme ºs elapsed and the hob ºs beepºng, press any key and
the alarm and dºgºt sequence wºll end.
7) It ºs possºble to adjust the tºmer tºme whºle the tºmer ºs prevºously
runnºng.
8) Power of tºmed zone can be modºfºed wºthout consequences on the
tºmer programmºng.
9) Last mºnute wºll be dºsplayed by seconds (For Varºants only vºsºble ºf
we enter the tºmer programmºng whºle the last mºnute of the
countdown)
10) Pressºng the Tºmer key wºthout any selected zone and when no
zone ºsbeºng tºmed, does nothºng.
11) Pressºng the Tºmer key wºthout any selected zone and when many
zones are beºng tºmed, the tºme shown ºntºme dºgºts changes ºna
rotatory way, and shows the tºme whose power dºsplay has the
decºmal poºnt ON.
12) Alternatºvely Power (5s) and (0,5s) ºsdºsplayed ºn the zone beºng
tºmed.
Remaºnºng tºme ºsdºsplayed ºn the dºgºts reserved for the tºmer. If
multºple zones are tºmed, the smallest remaºnºng tºme ºsdºsplayed,
and the decºmal poºnt ºsdºsplayed º
n the correspondºng zone.
