INSTALLATION(AIR DEFLECTOR FOR T-SHAPE,CURVED GLASS,FLAT
GLASS MODELS):
Air deflector is mentioned as included and not optional.
1.Before installation,cu rve both ends of the bracket as shown below:
2.Fix the b r acket to the T-shaped plastic outlet with 2pcs ST3.5x12mm screws
provided.
3.Drill 2 holes to accommodate the wall p lugs,then screw and tigh ten the
bracket onto the wall with 2pcs ST4x30mm screws provided.
