Cannondale SLICE Series - Page 9

7
127399.PDF
Park Tool SG-8: www.parktool.com/product/threadless-saw-guide-for-carbon-composite-forks-sg-8
Park Tool CSB-1: www.parktool.com/product/carbon-saw-blade-csb-1
UPPER CLAMP
LOWER CLAMP
Apply carbon gel KF115/ to seat post.
UCI Time Trial Triathlon Time Trial
KP273/WHT
KP273/BLE
110mm Maximum Insert
80mm Minimum Insert
(a)
FRONT
OF
BIKE
FRONT OF BIKE
5 Nm, 44 InLbs
“80mm MIN. INSERT”
KP274/
Apply light grease
to wedge assembly.
Saddle angle
adjust.
