Canon FOCUSING RAIL - Parts List; Component Listing

REF.NO.C42-6521
P A R T S L I S T
Pg.1
Report.No. NEW PARTS NO. CLASS QTY DESCRIPTION
AS-595 CY1-4258-000 C 2 STOPPER, RACK
AS-595 CY1-4259-000 C 1 NUT
AS-595 CY1-4260-000 D 1 RAIL
AS-595 CY1-4261-000 D 1 SHAFT, FOCUSING
AS-595 CY1-4262-000 C 1 KNOB, FOCUSING
AS-595 CY1-4263-000 C 1 KNOB, FOCUSING
CA4-1574-000 B 2 RUBBER, KNOB
CA4-1575-000 B 1 RUBBER, LOCK KNOB
CA4-1576-000 A 2 COVER
CA4-1577-000 B 1 SCREW
AS-595 CY1-4264-000 B 1 KNOB, LOCK
AS-595 CY1-4265-000 C 1 KNOB, LOCK
CA4-1581-000 D 1 SLIDING SUPPORT
CA4-1582-000 B 1 RUBBER, LOCK KNOB
AS-595 CY1-4266-000 D 1 GEAR, PINION
AS-595 CY1-4267-000 D 1 RACK
CS1-8150-000 C 1 PLATE, NAME
XA1-3200-606 3 SCREW
XA1-3260-606 2 SCREW
XA1-6170-509 4 SCREW
XD1-1102-631 N WASHER
XD1-1102-632
XD1-1105-719 1 WASHER
XD3-1200-052 1 PIN, SPRING
XD3-1300-082 2 PIN, SPRING
XD3-1300-162 1 PIN, SPRING
