• Press Back to access a higher menu in the menu list, and press OK to access a lower one. If not all menu items
are displayed, hold down ▲ or ▼ to scroll through higher and lower menu items. Items you select are highlighted.
The scroll bar at right indicates the current position in the overall menu.
• Lower menus are available if is displayed at right next to the second and subsequent rows. To access the low-
er menus, select the menu and press the OK button.
Specifying menu items
Menu items can be set as follows.
1
Press ▲ or ▼ to select the desired setting, and then press the OK button.
After two seconds, the display reverts to the upper level menu.
Note
• If a confirmation message is displayed regarding the setting you entered, press the OK button. The setting is applied,
and the printer is now in Standby.
Menu Operations iPF760
User's Guide
Control Panel Printer Menu
484

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
