Canon imagePROGRAF iPF810 Brochure & Specs

The new imagePROGRAF iPF820/810
printers are single-solution systems built
to satisfy the full range of large-format
technical document printing requirements
professionals encounter every day.
DUAL MEDIA ROLLS
Equipped with dual media rolls, the
iPF820 printer eliminates the cause
of many bottlenecks in busy printing
environments. It can automatically
switch between different size and
types of media or print on the same
media to enable fast, consecutive printing
of jobs submitted by multiple users.
VERSATILE OUTPUT UP TO 44"- WIDE
Print what you need, when you need
it. With the auto rotation and nesting
functionality on HP-GL/2 files, the
iPF820/810 printers not only maximize
throughput, but they also help save on
media consumption and per-print costs.
AUTOMATIC BLACK INK SELECTION
Based on the type of media being
used, the printer will automatically
select the right type of black ink for
best results: pigment Matte Black for
uncoated and technical papers or dye
Black for coated and glossy media.
BORDERLESS PRINTING
Print from edge-to-edge.* Output can
be ready to use without additional
trimming and finishing when utilizing
the borderless printing option.
SELF-PROPELLED CUTTER
The double rotary blade cutter is driven
separately from the print-head carriage
so that cutting can start immediately
after printing is finished. The result is
faster, continuous throughput.
PRINT LONGER WITHOUT INTERRUPTION
Canon’s unique sub-ink tank system
means you can replace ink on-the-fly,
without stopping the printer. Choose
the extra large 700ml ink tanks for
even greater productivity.
MEDIA DETECTION SYSTEM
The automatic media detection and
management system keeps track of
paper usage and warns the user if
there’s not enough media to complete
a print task.
HIGH-CAPACITY MEDIA BASKET
For long print runs, a high-capacity
media basket comes standard on
both the iPF820 and iPF810 printers.
Productivity – Maximized
*Up to 42" wide

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
