SPECIFICATIONS
Print-Heads
PF-03 (2)
Technology
FINE (Full-photolithography Inkjet Nozzle Engineering)
C
onfiguration
Two Print-Heads
Print-Head (L) Y/PC/C/PGY/GY/MBK
Print-Head (R) PM/M/BK/R/G/B
Number of Nozzles
2,560 per Color; 30,720 Total
D
roplet Size
U
niform 4 Picoliter for All Colors
Nozzle Pitch (Head Resolution)
Up to 1200 dpi
Print-Head Swath
1.07 inch
P
rint Resolution (Max.)
2400 x 1200 dpi
I
nk Type
LUCIA Ink (Pigment-based)
Replacement Ink Tank
PFI-702 (700ml) or PFI-302 (330ml) for Bk/MBk/GY/PGY
PFI-701 (700ml) or PFI-301 (330ml) for C/M/Y/PC/PM/R/G/B
C
olors
Cyan, Photo Cyan, Magenta, Photo Magenta, Yellow,
Black, Matte Black, Red, Green, Blue, Gray, Photo Gray
Ink Tank Shipped with Printer
12 Colors (Full 330ml Each Color)
I
nk Supply Method
Tubing System with Sub-Tanks for Continuous Ink Supply
Nozzle Recovery System
Non-firing Nozzle Detection and Compensation
Printer Controller
L-COA Controller
Printer Memory
640MB
Hard Disk Capacity
80GB
Media Feed
Roll Feed
One Roll, Front-Loading, Front Output
Cut Sheet
One Sheet, Front-Loading, Front Output
Media Width
Roll Feed
10”– 60”
Cut Sheet
8”– 60”
Minimum Media Length
8” (203mm)
Maximum Print Length
Manual Feed
63” (1.6m)
Roll Feed
59’ (18m)*
Borderless Printing Width (Roll Media Only)
10”, 14”, 16”, 24”, 36”, 42”
B2 (20.28”/515mm), A1 (23.38”/594mm)
A0 (33.11”/841mm), B0 (40.55”/1030mm)
Media Cutter
User-replaceable Durable Rotary Blade (CT-06)
M
edia Thickness
0.07mm–0.8mm (2.8mil–31.4mil)
M
edia Core Sizes
2” (3” Core with Optional 3” Core Spool)
Media Output
Automatically Winding Media Take-up Reel,
B
asket (Optional)
Printable Margins
Manual Feed (Top/Front)
Leading and Left/Right Edges: 0.20” (5mm),
Trailing Edge: 0.90” (23mm)
Roll Feed
All Sides: 0.20” (5mm) or 0” for Borderless
Maximum Media Roll Outer Diameter
5.9” (150mm)
Built-in Hard Disk Capacity
80GB
Bundled Software
Printing Software
Canon Printer Driver, Print Plug-in for Photoshop
®
,**
Print Plug-in for Digital Photo Professional, Printer Driver
Extra Kit
5
(Free Layout, imageRUNNER
®
Linking Function),
Print Plug-in for Microsoft Office
55
Applications
Digital Photo Front-Access
55
PosterArtist (Optional)
55
Utilities
GARO Status Monitor with SMTP E-mail Printer Status
Notification, Media Configuration Tool, Remote UI
Printer Language
GARO (Canon Proprietary)
Operating System
g
Windows
®
2000 (32 bit), XP (32/64 bit), Server 2003
(32/64 bit), Server 2008 (32/64 bit), Windows Vista
®
(32/64
bit), Windows 7 (32/64 bit);
Macintosh
®
OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 -
10.6 (64 bit)
Interface
Standard
USB 2.0; 10/100Base-T/TX
Optional
IEEE1394 (FireWire
®
)
Acoustic Noise
Operation
51dB or Less
Standby
35dB or Less
Acoustic Power (Operation and Standby)
6.7 Bels or Less
Power Supply
AC 100–240V (50–60Hz)
Power Consumption
Maximum
190W or less
Standby (100–120V)
5W or less
Power Off (Standby, 100–120V)
Less than 1W
(Compliant with Executive Order)
Certifications
Electrical Safety Regulations
UL (USA), C-UL (Canada), S mark (Argentina),
C
B certification (Others)
Electromagnetic Interface Regulations
FCC Class B (USA), IC Class B (Canada)
Environmental Certifications
ENERGY STAR
®
(World Wide), RoHS Directive,
WEEE, Executive Order (USA)
O
perational Environment
Temperature
59–86 F° (15–30 C°)
Relative Humidity
10–80% (Condensation Free)
Dimensions with Stand (H x W x D)
45" x 90.5" x 30.2" (1144mm x 2299mm x 766mm)
W
eight with Stand
Approx. 362 lb. (162kg)
U
ser-Replaceable Items
Ink Tanks
Print-Head (PF-03)
M
aintenance Cartridge (MC-08)
Durable Rotary Media Cutter (CT-06)
Options
IEEE1394 Expansion Board (EB-05)
Basket (BU-01)
PosterArtist
2” Core Roll Holder (RH2-63)
3” Core Roll Holder (RH3-63)
* The maximum printable length varies depending on the application,
OS, and RIP used. The maximum printable length from Canon
Printer Driver is 50 feet.
** For Adobe Photoshop 6, 7, CS, CS2, CS3, CS4 running on
Windows 2000/XP/Windows Vista (32/64 bit)/Windows 7 (32/64
bit) or Macintosh OS X 10.2/10.3/10.4/10.5/10.6.
5
Not compatible with Windows 64-bit OS.
55
Windows 2000/XP/Windows Vista/Windows 7 (32 bit)
g
For Canon Printer Driver. For printing from PostScript
®
applications
such as Adobe Illustrator
®
or QuarkXPress
®
, please use a
PostScript compatible RIP package. For a list of Canon
recommended RIP packages, please consult with Canon Alliance
and Industry Market program list of RIP vendors.
iPF9100
Océ North America
Wide Format Printing Systems
5450 N. Cumberland Ave.
Chicago, IL 60656
For more information, call us at 800-714-4427, email
us.info@oce.com, or visit www.oceusa.com.
ES-51200 C-10-2010 PDF
As an ENERGY STAR
®
Partner, Canon U.S.A., Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. ENERGY
STAR and the ENERGY STAR mark are registered U.S. marks.
Océ and the Océ logo are registered trademarks owned by Océ-Technologies B.V.
CANON,
IMAGEPROGRAF, LUCIA, and the GENUINE logo are registered trademarks of Canon Inc. in the United States and may also be registered trademarks
or trademarks in other countries. IMAGEANYWARE is a trademark of Canon. All other referenced product names and marks are trademarks of their
respective owners and are hereby acknowledged. Some items may not be available at this time; please check for availability. Specifications and
availability subject to change without notice. All printer output images are simulated.
©2010 Canon U.S.A., Inc. All rights reserved.
